                                      Product Highlight

==========================================================================================

Specifications

Capacity: 1TB

Standard Model Number : ST1000DM010

Bytes per Sector: 4,096

Performance

Interface: SATA 6Gb/s

SATA Transfer Rates Supported (Gb/s): 6.0/3.0/1.5

Max Sustained Data Rate, OD Read (MB/s): 210MB/s

Cache, Multi-segmented (MB): 64

Rotational Speed (RPM): 7,200

Recording Technology: CMR

Reliability/Data Integrity

Load/Unload Cycles: 50,000

Non-recoverable Read Errors per Bits Read, Max: 1 per 10E14

Power-On Hours (per year): 2,400

Workload Rate Limit (TB/Year): 55

Warranty, Limited (years): 2

Power Management

Startup Power (A): 2

Operating Mode, Typical (W): 5.3

Idling Average (W): 4.6 W

Standby Mode/Sleep Mode, Typical (W): 0.94/0.94

Voltage Tolerance, Inc. Noise (5V): ±5%

Voltage Tolerance, Inc. Noise (12V): ±10%

Environmental/Temperature

Operating (ambient, min): 0°C

Operating (drive case, max): 60°C

Non-operating (ambient): -40°C – 70°C

Halogen-free: Yes

RoHS compliance: Yes

Physical

Height (mm/in, max): 19.99 mm/0.787 in

Width (mm/in, max): 101.85 mm/4.01 in

Depth (mm/in, max): 146.99 mm/5.787 in

Weight (g/lb, typical): 400 g/0.88 lb

Carton Unit Quantity: 25

Cartons per Pallet / Cartons per Layer: 40/8
