PERFORMANCE
Processor
Intel Core™ Ultra 7 251HX, 18C (6P + 12E) / 18T, Max Turbo up to 5.1GHz, 30MB Intel® Smart Cache
AI PC Category
AI PC, AI-Powered Gaming PC
NPU
Integrated Intel® AI Boost, up to 13 TOPS
Graphics
NVIDIA GeForce RTX™ 5060 8GB GDDR7, Boost Clock 2497MHz, TGP 115W, 572 AI TOPS
Chipset
Intel® HM870 Chipset
Memory
1x 16GB SODIMM DDR5-5600
Memory Slots
Two DDR5 SODIMM slots, dual-channel capable
Max Memory
Up to 32GB DDR5-5600 offering
Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot
Two M.2 slots
• One M.2 2242 PCIe® 5.0 x4 slot
• One M.2 2280 PCIe® 4.0 x4 slot
Max Storage Support
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 2TB
Optical
None
Card Reader
No Card Reader
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio
Microphone
2x, Array
Camera
5.0MP with E-shutter
Battery
80Wh
Power Adapter
245W Slim Tip (3-pin)
Special Features
AI Chip: LA1
DESIGN
Display
15.3" WQXGA (2560x1600) OLED 1000nits (peak) / 500nits (typical) Glossy, 100% DCI-P3, 165Hz, G-SYNC®, DisplayHDR™ True Black 1000
Touchscreen
None
Screen-to-Body Ratio
92% AAR (active area ratio)
Color Calibration
X-Rite® Factory Color Calibration
Pen
Pen Not Supported
Keyboard
1-Zone RGB Backlit, English
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Dimensions (WxDxH)
344 x 244.5 x 18.95-19.95 mm (13.54 x 9.63 x 0.75-0.79 inches)
Weight
Starting at 1.93 kg (4.25 lbs)
Case Color
Glacier White
Case Material
Aluminium (Top), PC-ABS (Bottom)
Surface Treatment
SUV Painting
SOFTWARE
Operating System
Windows® 11 Home Single Language, Simplified Chinese / English
Bundled Software
Office Trial + Lenovo® AI Now
CONNECTIVITY
WLAN + Bluetooth
Wi-Fi® 7, 802.11be 2x2 + BT5.4
WWAN
WWAN Not Supported
Ethernet
100/1000M (RJ-45)
Standard Ports
1x USB-A (USB 5Gbps), Always On, with 10W output
2x USB-A (USB 5Gbps), with 4.5W output
1x USB-C® (USB 10Gbps), with USB PD 65-100W input / 15W output and DisplayPort™ 2.1
1x Thunderbolt™ 4, with USB PD 65-100W input / 15W output and DisplayPort™ 2.1
1x HDMI® 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Slim tip (rectangle) power connector
Docking
Various docking solutions supported via Thunderbolt™ / USB-C®.
For more compatible docking solutions, please visit Docking for Legion 5 15IAX11
SECURITY & PRIVACY
Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
No Fingerprint Reader
Other Security
E-shutter
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
2Y Premium Care -IPMAIN (ESS)
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ErP Lot 6/26
RoHS compliant
Mil-Spec Test
MIL-STD-810H military test passed
Other Certifications
Pantone® SkinTone™ Validated
Pantone® Validated
TÜV Rheinland® Flicker Free
TÜV Rheinland® High Gaming Performance
TÜV Rheinland® Low Blue Light (Hardware Solution)
