Product Highlight

==========================================================================================

FAN PROFILE

Addressable Gen 2 RGB

FAN SPEED

650-1800 RPM (PWM) ± 10%

FAN AIRFLOW

47.2 CFM ± 10%

FAN AIR PRESSURE

1.6 mmH2O ± 10%

FAN NOISE LEVEL

6 - 30 dBA

FAN DIMENSIONS (L X W X H)

120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch

FAN MTTF

160,000 Hours

FAN BEARING TYPE

Rifle Bearing

FAN POWER CONNECTOR

4-Pin (PWM)

FAN RATED VOLTAGE

12VDC

FAN RATED CURRENT

0.25A

FAN SAFETY CURRENT

0.37A

RGB CONNECTOR

3-Pin

RGB RATED VOLTAGE

5V DC

RGB RATED CURRENT

0.55A (0.80 Max)

FAN POWER CONSUMPTION

3.0W

FAN WEIGHT

180g / 0.4lbs

WARRANTY

2 years

SERIES

MasterFan

COOLER TYPE

Case Fan

FAN SIZE

120

FAN - LED LIGHTING

ARGB

NOTE

Products manufactured after 1st June 2021 are Addressable Gen 2 RGB LEDs
