odel No.

SST- FA312-BG

Material

Steel, plastic, tempered glass

Motherboard

Micro-ATX (9.6" x 9.6"), Mini-DTX (8" x 6.7"), Mini-ITX (6.7" x 6.7")

Drive bay

Internal

3.5"/ 2.5 x 2 (only 1 form factor can be installed at the same time)

2.5" x 3 (1 x 2.5" SSD is installed on the motherboard tray, which will interfere if 140mm fan or 280mm radiator is installed at the front)

Cooling system

Front

120mm x 3 / 140mm x 2

Rear

120mm x 1 (120mm x 1 black fan included)

Top

120mm x 2 / 140mm x 2

Radiator support

Front

120mm / 140mm / 240mm / 280mm

Rear

120mm

Top

120mm / 140mm / 240mm / 280mm

(When installing 280mm radiator, please make sure the components inward on the motherboard is below 24mm to avoid interference)

Limitation of CPU cooler

173mm

Expansion slot

4

Limitation of expansion card

Length : 365mm (incl. front 25mm thickness fan installed)

350mm (applies only to 120mm front fans when installed between the front panel and chassis)

Width : 182mm

Power supply

Standard PS2 (ATX)

Limitation of PSU

170mm

Front I/O port

USB 3.0 x 2

Audio x 1

Mic x 1

Dimension

220mm (W), x 410mm (H), x 412.5mm (D), 37.21 liters

8.66" (W), x 16.14" (H), x 16.24" (D), 37.21 liters

Net weight

5.5 kg
