Form Factor
M.2 2280

Interface
PCIe Gen4x4

Speed
500GB—Sequential read up to 5000MB/s, sequential write up to 2600MB/s
1TB—Sequential read up to 5000MB/s, sequential write up to 4500MB/s

Operating Temperature
0°C to 70°C (32°F to 158°F)

Storage Temperature
-40°C to 85°C (-40°F to 185°F)

Dimensions (L x W x H)
80 x 22 x 2.45 mm (3.15” x 0.87” x 0.10”)

Weight
7g (0.015lbs)

Shock-resistant
1500G, duration 0.5ms, Half Sine Wave

Vibration-resistant
10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis(X,Y,Z)

TBW
500GB: 300TBW, 1TB: 600TBW, 2TB: 1200TBW

MTBF
1,500,000 Hours
