PERFORMANCE
Processor
AMD Ryzen™ Z2 Extreme (8C / 16T, 2.0 / 5.0GHz, 8MB L2 / 16MB L3)
Graphics
Integrated AMD Radeon™ Graphics
Chipset
AMD SoC Platform
Memory
32GB Soldered LPDDR5x-8000
Memory Slots
Memory soldered to systemboard, no slots
Max Memory
32GB soldered memory, not upgradable
Storage
1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot
One M.2 2280 PCIe® 4.0 x4 slot
Max Storage Support
One drive, up to 1TB M.2 2242 SSD or 2TB M.2 2280 SSD
Optical
None
Card Reader
microSD Card Reader
Audio Chip
High Definition (HD) Audio
Speakers
Stereo speakers, 2W x2 (woofers)
Microphone
2x, Array
Camera
None
Battery
74Wh
Power Adapter
65W USB-C® Slim (2-pin, Wall-mount)
Special Features
Legion Coldfront 2.0 cooling system
DESIGN
Display
8.8" WUXGA (1920x1200) OLED 500nits (typical) / 1100nits (peak) Glossy / Anti-fingerprint, 100% DCI-P3, 144Hz, DisplayHDR™ True Black 1000, Corning® Gorilla® Glass 3, Low Blue Light, Touch
Touchscreen
In-cell, 10-point Multi-touch
Screen-to-Body Ratio
85.8% AAR (active area ratio)
Pen
Pen Not Supported
Touchpad
Buttonless Mylar® surface touchpad (on the right controller), 24 x 24 mm (0.94 x 0.94 inches)
Controls
A B X Y buttons
D-pad
Touchpad
FPS mode switch
Mouse wheel (on right controller)
Left & right Joysticks
Left & right release buttons
LB & LT buttons
RB & RT buttons
Y1 & Y2 buttons
M3 & Y3 buttons
M1 & M2 buttons
6x function buttons
Dimensions (WxDxH)
Gamepad | 206 x 136.7 x 22.95 mm (8.11 x 5.38 x 0.90 inches)
Gamepad with controllers | 295.6 x 136.7 x 42.25 mm (11.64 x 5.38 x 1.66 inches)
Weight
Gamepad with controllers | Around 920 g (2.03 lbs)
Controllers only | Less than 210 g (0.46 lbs)
Case Color
Eclipse Black
Case Material
PC-ABS (Gamepad), PC-ABS (Controllers)
Surface Treatment
Painting (Gamepad), Painting + Special Texture (Controllers)
Others
Power button
Volume keys
SOFTWARE
Operating System
Windows® 11 Home, Simplified Chinese / English
Bundled Software
Office Trial
CONNECTIVITY
WLAN + Bluetooth
Wi-Fi® 6E, 802.11ax 2x2 + BT5.3
WWAN
Non-WWAN
Ethernet
No Onboard Ethernet
Standard Ports
2x USB-C® (USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
2x USB-C® (support charging only)
1x Headphone / microphone combo jack (3.5mm)
1x Card reader
Docking
Various docking solutions supported via USB-C®.
For more compatible docking solutions, please visit Docking for Legion Go 8ASP2
SECURITY & PRIVACY
Security Chip
Microsoft® Pluton TPM 2.0 Enabled
Fingerprint Reader
Touch Style, Integrated in Power Button
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
3Y Depot/CCI-IPENTRY (ESS)
ACCESSORIES
Bundled Accessories
Carry Bag (with Controller Dock), Controller Protecting Cover (for FPS mode)
