Processor
Intel® Core™ i7-14700, 20C (8P + 12E) / 28T, Max Turbo up to 5.4GHz, P-core 2.1 / 5.3GHz, E-core 1.5 / 4.2GHz, 33MB

Graphics
Integrated Intel® UHD Graphics 770

Chipset
Intel® B660 Chipset

Memory
1x 8GB UDIMM DDR4-3200

Memory Slots
Two DDR4 UDIMM slots, dual-channel capable

Storage
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe®

Storage Support
Up to two drives, 1x 3.5" HDD + 1x M.2 SSD
• 3.5" HDD up to 2TB
• M.2 SSD up to 1TB

Card Reader
7-in-1 Card Reader

Optical
None

Audio Chip
High Definition (HD) Audio, Realtek® ALC623-CG codec

Speakers
No speakers

Power Supply
260W 85%

Keyboard
USB Calliope Keyboard, Black, English

Mouse
USB Calliope Mouse, Black

Expansion Slots
Two M.2 slots (one for WLAN, one for SSD)

Case Color
Cloud Grey

System
Fan 2x default

Form FactorSFF (7.4L)

Dimensions (WxDxH)

100 x 303.5 x 274.8 mm (3.9 x 11.94 x 10.8 inches)

Weight
4.4 kg (9.8 lbs)

CONNECTIVITY
Ethernet Integrated 100/1000M
WLAN + Bluetooth Wi-Fi® 6, 11ax 2x2 + BT5.1

Front Ports
1x USB-C® 3.2 Gen 1 (support data transfer and 5V@3A charging)
2x USB 3.2 Gen 1
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)

Rear Ports
2x USB 2.0
2x USB 3.2 Gen 1
1x HDMI® 2.1 TMDS
1x VGA
1x Ethernet (RJ-45)
1x audio-out (3.5mm)

SECURITY & PRIVACY
Security Chip Firmware TPM 2.0 integrated in chipset

MANAGEABILITY
System Management None

SERVICE
warranty 3 Year Premium Care onsite - Idea DT (ESS)

CERTIFICATION
Green CertificationsErP Lot 3
RoHS compliant

SOFTWARE
Operating System Windows® 11 Home Single Language, Simplified Chinese / English

Bundled Software
Office Home & Student 2021
