Dimensions
48.5 mm × 48.5 mm × 13 mm
*Product size, product weight, and related specifications are theoretical values only. Actual measurements between individual products may vary. All specifications are subject to the actual product.
Wrist Size
140-210 mm
Weight
Approximately 76 g (strap excluded)
*Product size, product weight, and related specifications are theoretical values only. Actual measurements between individual products may vary. All specifications are subject to the actual product.
Display
Size
1.5 inches LTPO AMOLED color screen
Resolution
466 × 466 pixels, PPI 311
Watch Case
Color
Steel-color
Material
Watch dial: sapphire glass
Watch Bezel: nanocrystalline ceramic
Front case: zirconium-based liquid metal
Rear case: nanocrystalline ceramic
Watch Strap
Titanium Strap
(with a blue HNBR strap comes in the product packaging)
Sensors
Accelerometer sensor
Gyroscope sensor
Magnetometer sensor
Optical heart rate sensor
Barometer sensor
Temperature sensor
Depth sensor
Button
Three buttons: assist button, rotating crown, function button
Charging Port
Wireless charging
System Requirements
Android 6.0 or later
iOS 9.0 or later
Waterproof Level
10 ATM water-resistant
*This product complies with 10 ATM-rated 100-metre water resistance under the ISO 22810:2010 standard, and can be worn during shallow water activities, such as swimming in pools and shallow waters along the coast.
Connectivity
NFC
Supported
Bluetooth
2.4 GHz, supports BT5.2 and BR+BLE
Environment
Ambient Operating Temperature
-20?–+45?
Battery Life
Typical usage: 14 days
30 minutes of Bluetooth calling every week, 30 minutes of audio playback every week, heart rate monitoring enabled, HUAWEI TruSleep™ enabled for sleeping, 90 minutes of working out every week (GPS enabled), message notifications enabled (50 SMS messages, 6 calls, and 3 alarms a day), screen is turned on 200 times a day.
Heavy usage: 8 days
30 minutes of Bluetooth calling every week, 30 minutes of audio playback every week, heart rate monitoring enabled, HUAWEI TruSleep™ enabled for sleeping, stress monitoring enabled, 180 minutes of working out every week (GPS enabled), message notifications enabled (50 SMS messages, 6 calls, and 3 alarms a day), screen is turned on for 30 minutes a day.
*Based on results from HUAWEI lab tests. The actual usage may vary depending on product differences, user habits, and environment variables.
Speaker
Supported
Microphone
Supported
Charging
Charger Voltage and Current Requirements
5V-9V DC / 2A
In The Box
Watch × 1
Charging Cradle (including the charging cable) × 1
Quick Start Guide & Safety Information & Warranty Card × 1
