Bambu Lab A2L – Technical Specifications
Body    Build Volume (WxDxH)
330mm x 320mm x 325 mm
Chassis
Aluminum and Steel
Outer Frame
Plastic
Dimensions and Weight
Physical Dimensions
544mm x 529mm x 505 mm
Net Weight
12.8 kg
(Gross Weight: A2L 17.0 kg, A2L AMS Combo 18.9kg)
Toolhead    Extruder Gear
Hardened Steel
Nozzle
Stainless Steel
Max Nozzle Temperature    300 °C
Supported Nozzle Diameter    0.2 mm, 0.4 mm, 0.6 mm, 0.8 mm
Filament Cutter
Built-in
Filament Diameter    1.75 mm
Extruder Motor
Servo Extruder Motor
Heatbed
Build Plate Material
Flexible Steel Plate
Included Build Plate Type
Textured PEI Plate
Supported Build Plate Type
Textured PEI plate, Engineering Plate, Cool Plate SuperTack
Max Heatbed Temperature    80 ℃
Speed    Max Speed of Toolhead    500 mm/s
Max Acceleration of Toolhead    10 m/s²
Max Flow for Hotend
28 mm³/s
(Test parameters: 150 mm round model with a single outer wall; Bambu Lab PLA Basic; 220 °C printing temperature)
Cooling
Part Cooling Fan
Closed Loop Control
Hotend Cooling Fan
Closed Loop Control
Supported Filament Type
PLA, PETG, TPU, PVA
Suitable for Printing
PLA-CF、PETG-CF
Suitable for Printing (Replace with Hardened Steel Nozzle)
Sensor
Camera
Low-frame-rate camera, up to 1080P, supports timelapse photography
Filament Run Out Sensor
Supported
Filament Tangle Sensor
Supported
Filament Odometry
Supported
Power Loss Recovery
Supported
Clumping Detection
Supported
Electrical Requirements*    Voltage
High-voltage Version: 200-240 VAC, 50/60 Hz
Low-voltage Version: 100-120 VAC, 50/60 Hz
Max Power*
High-voltage Version: 1000 W@220 V
Low-voltage Version: 1000 W@110 V
Please purchase the version corresponding to your region’s voltage. Using the Printer in different regions, you may need to purchase a power adapter accordingly.
Environment Requirement
15 -30 °C
Electronics    Touchscreen
3.5 inch, 240*320 Touchscreen
Storage
32g MicroSD Card
Control Interface
Touchscreen, mobile App, PC App
Motion Controller
Single-core Cortex-M4 Processor & Single-core Cortex-M7 Processor
Communication
Wi-Fi, Bambu-Bus
Software    Slicer
Bambu Studio
Supports third-party slicers which export standard Gcode, such as Super Slicer, PrusaSlicer and Cura, but certain advanced features may not be supported.
Supported Operating System
MacOS、Windows、Linux
Network Control
Ethernet
Not Available
Wireless Network
2.4G Wi-Fi
Wi-Fi    Operating Frequency
2412 – 2472 MHz (CE/MIC)
2412 – 2462 MHz (FCC)
2400 – 2483.5 MHz (SRRC)
Wi-Fi Transmitter Power (EIRP)
<23 dBm (FCC), <20 dBm (CE/SRRC)
Wi-Fi Protocol
IEEE 802.11 b/g/n
*The printer’s voltage specifications vary by sales region. Before use, check the label next to the power socket to ensure the supply voltage matches the indicated voltage.
To ensure the heatbed quickly reaches the needed temperature, the printer will maintain maximum power for about 3 minutes.
Cutting Module
Cutting Area
300mm * 300 mm
Drawing Area
300mm * 255 mm
Supported Pen Diameter
10.5 mm–12.5 mm
Cutting Mat Type
LightGrip and StrongGrip Cutting Mats
Blade Type
45°0.35 mm
Blade Pressure Range
50 gf–600 gf
Max Cutting Thickness
0.5 mm
Blade and Pen Recognition
Supported
Cutting Mat Type Detection
Supported
Supported Image Type
Bitmap and Vector Images
Supported Material Type
Paper, PVC, vinyl, leather, and more
