Capacity
1TB (1,024GB) / 2TB (2,048GB) / 4TB (4,096GB)

Form Factor
M.2 2280

NAND Flash
3D NAND

Controller
IG5236

Dimensions (L x W x H)
80 x 22 x 4.3mm / 3.15 x 0.87 x 0.17inch (with heatsink)

Weight
10g / 0.35oz (with heatsink)

Interface
PCIe Gen4x4

Sequential Read (Max*)
Up to 7400MB/s (PC/Laptop),

Sequential Write (Max*)
Up to 6800MB/s

4KB Random Read IOPS(Max*)
Up to 750K

4KB Random Write IOPS(Max*)
Up to 750K

Operating Temperature
0°C - 70°C

Storage Temperature
-40°C - 85°C

Shock Resistance
1500G / 0.5ms

MTBF
2,000,000 hours
