GPU

AMD Radeon™ RX 6600 Graphics Card

7nm GPU

AMD RDNA™ 2 Architecture

Engine Clock

Boost Clock: Up to 2491 MHz

Game Clock: Up to 2044 MHz

Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads.

Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.

Stream Processors

1792

Infinity Cache

32MB

Ray Accelerators

28

Memory Size/Bus

8GB GDDR6

Memory Clock

14 Gbps Effective

Displays

Maximum 4 Displays

Resolution

HDMI™: 7680×4320

DisplayPort1.4: 7680×4320

Interface

PCI-Express 4.0 x8

Output

1x HDMI

3x DisplayPort

BIOS Support

UEFI

Game Index

1080P

Sapphire Features

Premium Digital Power Design

Fuse Protection

Dual-X Cooling Technology

Intelligent Fan Control

Precision Fan Control

Metal Backplate

Two-Ball Bearing Fans

TriXX Supported

TriXX Boost

AMD Features

AMD RDNA™ 2 Gaming Architecture

DirectX® 12 Ultimate

Hardware Raytracing

Smart Access Memory

Infinity Cache

7nm GPU

PCI® Express 4.0 Support

AMD FreeSync™ Technology

DisplayPort™ 1.4 with DSC

HDMI™

Video Streaming up to 8K

Radeon™ VR Ready Premium

AMD FidelityFX

Radeon™ Image Sharpening

Radeon™ Anti-Lag

Radeon™ Software

Game Driver Optimizations

Cooling

Dual Fans

Form Factor

2 slot, ATX

Dimension: 193(L)X 120.05(W)X 40.05(H)mm

Power Consumption

140W (Board Power)

OS

Linux®, Windows® 7*, Windows® 10, and Windows 11 64-bit  operating system required

*Does not support all features including but not limited to Hardware Raytracing

System Requirement

Minimum 500 Watt Power Supply

1 x 8-pin Power Connector.

PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.

Minimum 8GB of system memory. 16GB recommended.
