Graphics Engine

- AMD Radeon™ RX 7700 XT

Bus Standard

- PCI® Express 4.0 x16

DirectX

- 12 Ultimate

OpenGL

- 4.6

Memory

- 12GB GDDR6

Engine Clock

- Boost Clock*: Up to 2599 MHz

- Game Clock**: 2276 MHz

*Boost Clock is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.

**Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.

Stream Processors

- 3456

Memory Clock

- 18 Gbps

Memory Interface

- 192-bit

Resolution

- Digital Max Resolution: 7680 x 4320

Interface

- 3 x DisplayPort™ 2.1*

- 1 x HDMI™ 2.1

*DisplayPort (DP) 2.1 on any one or two ports. DisplayPort (DP) 1.4a on any and up to 4 ports simultaneously.

HDCP

- Yes

Multi-view

- 4

Recommended PSU

- 750W

Power Connector

- 1 x 8-pin

Accessories

- 1 x Quick Installation Guide

Dimensions

- 304 x 131 x 56 mm, 2.8-slot

Net Weight

- 1242 g
