More Information

P/N

CA-1S4-00M1WN-00

SERIES

Divider

CASE TYPE

Mid Tower

DIMENSION (H X W X D)

491 x 220.3 x 469.1 mm

(19.3 x 8.7 x 18.5 inch)

NET WEIGHT

7.44 kg / 16.4 lbs.

SIDE PANEL

3mm Tempered Glass x 1

COLOR

Black

MATERIAL

SPCC

COOLING SYSTEM

Front(intake):

120 x 120 x 25 mm ARGB PWM fan (1500rpm, 27.2 dBA) x 2

Rear(exhaust):

120 x 120 x 25 mm ARGB PWM fan (1500rpm, 27.2 dBA) x 1

DRIVE BAYS

-ACCESSIBLE

-HIDDEN

2 x 3.5”, 2 x 2.5” or 4 x 2.5”

EXPANSION SLOTS

7

MOTHERBOARDS

6.7" x 6.7" (Mini ITX), 9.6" x 9.6" (Micro ATX),

12" x 9.6" (ATX), 12" x 13" (E-ATX)

I/O PORT

USB 3.0 x 2, HD Audio x 1

PSU

Standard PS2 PSU (optional)

FAN SUPPORT

Front:

3 x 120mm, 2 x 120mm, 1 x 120mm

3 x 140mm, 2 x 140mm, 1 x 140mm

Top:

3 x 120mm, 1 x 120mm

2 x 140mm, 1 x 140mm

Right (M/B Side):

2 x 120mm, 1 x 120mm

Rear:

1 x 120mm

RADIATOR SUPPORT

Front:

1 x 360mm, 1 x 240mm, 1 x 120mm

1 x 280mm, 1 x 140mm

Top:

1 x 360mm, 1 x 240mm, 1 x 120mm

1 x 280mm, 1 x 140mm

Right (M/B Side):

1 x 240mm, 1 x 120mm

Rear:

1 x 120mm

CLEARANCE

CPU cooler max height:

170mm

VGA max length:

340mm (with radiator)

400mm (without radiator)

PSU max length:

230mm (with HDD Cage)
