Product No.

SST-ST65F-ES230-BK

Color

Black?Lead-Free Paint?

Max. DC Output

650W

Power density

360W per liter

Load Range

Output+3.3V+5V+12V+5VSB-12V

Max.(Amps)20A20A50A2.5A0.3A

Peak (Amps)/////

Min.(Amps)0A0A0A0A0A

Range (%)±5%±5%±5%±5%±10%

Line Reg.(%)±1%±1%±1%±1%±1%

Ripple(mVp-p)50mV50mV120mV50mV120mV

Combined +3.3V & +5V

120W

Combined +12V

600W

Input Voltage

180V~264V

Input Frequency Range

47Hz~63Hz

PFC

Active PFC?PF>0.9 at full load?

Efficiency

82% ~ 85% at 20% ~ 100% loading

MTBF

100,000 hours

Operating temperature

0°C ~ 40°C

Protection

Over power protection

Over voltage protection

Short circuit protection

Connectors

1 x 24 / 20-Pin motherboard connector?500mm?

1 x 8 / 4-Pin EPS / ATX 12V connector?750mm?

4 x 8 / 6-Pin PCIe connector?"500mm / 150mm" x 2?

4 x SATA connector?"500mm / 150mm" x 2?

3 x 4-Pin Peripheral connector?500mm / 150mm / 150mm?

1 x 4-Pin Floppy connector?500mm / 150mm / 150mm / 150mm?

Cooling System

Single 120mm silent fan

Noise Level

18 dBA minimum

Certification

80 PLUS

Form factor

ATX

Dimension

150 mm (W) x 86 mm (H) x 140 mm (D)

Weight

1.42 kg

Other

GPU Support list

Compatible with ATX12V v2.4
